Camera & Image
1/2.9" CMOS image sensor
Full HD 2MP (1920×1080) resolution
2.8mm fixed lens, F1.6 aperture
Field of view: 103.8° (H), 56.8° (V), 120.4° (D)
WDR: 120dB
3D DNR, BLC, HLC, AGC, auto white balance
IR-cut filter with automatic switch (ICR)
Night Vision
IR distance: up to 30 meters (2 IR LEDs)
White light distance: up to 15 meters (2 LEDs)
Wavelength: 850nm
Smart IR support
Video & Audio
Video compression: S+265, H.265, H.264 (B/M/H)
Bit rate: 32Kbps ~ 4Mbps
Audio compression: G.711A, G.711U
Built-in microphone and speaker
Audio sampling rate: 8kHz / 16kHz
Networking
Wireless: IEEE802.11 b/g/n
Transmission distance: up to 50 meters (environment-dependent)
Frequency: 2.4 GHz
Channel bandwidth: 20/40MHz
Wi-Fi security: WPA-PSK / WPA2-PSK
Protocols: TCP/IP, UDP, DHCP, DNS, NTP, IPv4, SSH
Remote access via EasyLive Plus mobile app
Remote connection: up to 2 users
Storage & Interface
Supports microSD/microSDHC/microSDXC up to 256GB
Reset button
On-screen display overlay (up to 5 regions, 127 characters per region)
Smart Functions
Motion detection and smart alarm
Exception alarms: disk full, disk R/W error
Alarm linkage: sound, warmlight, recording, image capture
Build & Reliability
Weatherproof rating: IP65
Surge protection: 500V
ESD protection: 6000V
Operating temperature: -10°C to 50°C
Operating humidity: ≤95% RH
Power supply: DC 5V / 2A
Dimensions & Weight
Camera: 78 × 44 × 73 mm
Package: 146 × 83 × 108 mm
Weight: 0.38kg
